AX PRO User Manual
59
Note
It is recommended to use Gmail and Hotmail for sending mails.
4. Enter the receiver's information.
5. Click Receiver Address Test and make sure the address is correct.
6. Click Save.
FTP
You can configure the FTP server to save alarm video.
Steps
1. Click Communication→ FTP to enter the page.
2. Configure the FTP parameters
FTP Protocol
FTP and SFTP are selectable. The files uploading is encrypted by using SFTP protocol.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures. If the FTP server supports
picture uploading by anonymous users, you can check Anonymous to hide your device
information during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
What to do next
Enter the tasks the user should do after finishing this task (optional).
Set Video Parameters
Steps
1. Click Device →IPC→Video to enter the page.
To Next Page
