HIKVISION DS-2CD1143G0-I User Manual

Network Camera User Manual
189
b) Set the queue length level. Check one or more desired range checkboxes and
input values.
2. Select Report Type. Daily report, weekly report, monthly report and custom are
supported.
3. Select Statistics Time.
4. Click Counting to generate the report.
5. (Optional) Click Export in the upper right corner to export the data in desired
format (.txt and xls. are selectable.).
Raw Data
Storage of Raw Data
Raw data of queue management is saved in local storage of the device.
With an on-board memory card installed, the device can save up to one mouth’s data.
With NO memory card installed, the device can only save up to one week’s data.
Raw Data Exporting
Raw data exporting of queue management is not available on web browser. For
further analysis, you can get the data via RTSP protocol.
Open Platform
Purpose:
Open platform allows you to install the application for the third-party function
development.
Note:
 Only certain camera models support the function, and the actual display may vary
with your camera model.
 When you use the open platform function, it is not recommended to set your IP
address and the camera IP address to 192.168.252.X.
Steps:
1. Enter the Record Schedule Settings interface: Configuration > Open Platform.

HIKVISION DS-2CD1143G0-I Specifications

General

Video streaming	Yes
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Image quality adjustment	Brightness, Contrast, DNR, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Supported graphics resolutions	320 x 240, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440
Sensor type	CMOS
Number of sensors	-
Optical sensor size	1/3 \
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Maximum operating distance	30 m
DC output current	0.4 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	5 W
Power consumption (Power over Ethernet (PoE))	7 W
IK code	IK10
Form factor	Dome
Mounting type	Ceiling/wall
Product color	Black, White
Housing material	Metal, Plastic
International Protection (IP) code	IP67
Pan range	0 - 355 °
Tilt angle range	0 - 70 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0.01 lx
Field of view (FOV) angle	117 °
LED type	IR
Infra-red wavelength	850 nm
Wi-Fi	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Ethernet LAN (RJ-45) ports	1
Operating temperature (T-T)	-30 - 50 °C

Weight and Dimensions

Width	111 mm
Height	82.4 mm
Weight	410 g
Package weight	610 g
