Network Camera User Manual
75
3. Choose a friendly name for the camera, or you can use the default name.
4. Select the port mapping mode. Manual and Auto are selectable.
Note:
If you select Auto, you should enable UPnP™ function on the router.
If you select Manual, you can customize the value of the external port and
complete port mapping settings on router manually.
5. Click Save to save the settings.
Configuring Multicast
Purpose:
Multicast is group communication where data transmission is addressed to a group of
destination devices simultaneously. After setting up active multicast, you can send the
source efficiently to multiple devices.
Setting Multicast
Steps:
1. Enter the Multicast setting interface.
Configuration > Network > Basic Settings > Multicast
2. Set IP Address, Stream Type, Video Port, Audio Port, FEC Port and FEC Ratio of
the camera.
Notes:
