Network Camera User Manual
63
User Management Interface
Adding a User
The admin user has all permissions by default and can create/modify/delete other
accounts.
The admin user cannot be deleted and you can only change the admin password.
Steps:
1. Click Add to add a user.
2. Input the Admin Password, User Name, select Level and input Password.
Notes:
Up to 31 user accounts can be created.
Users of different levels own different default permissions. Operator and
user are selectable.
STRONG PASSWORD RECOMMENDEDWe highly recommend you
create a strong password of your own choosing (using a minimum of 8
characters, including at least three of the following categories: upper case
letters, lower case letters, numbers, and special characters) in order to
increase the security of your product. And we recommend you reset your
password regularly, especially in the high security system, resetting the
password monthly or weekly can better protect your product.
3. You can check or uncheck the permissions for the new user.
4. Click OK to finish the user addition.
Modifying a User
Steps:
1. Left-click to select the user from the list and click Modify.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2CD1143G0-I and is the answer not in the manual?

HIKVISION DS-2CD1143G0-I Specifications

General IconGeneral
Video streamingYes
Total megapixels4 MP
Maximum resolution2560 x 1440 pixels
Image quality adjustmentBrightness, Contrast, DNR, Saturation, Sharpness
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Supported graphics resolutions320 x 240, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440
Sensor typeCMOS
Number of sensors-
Optical sensor size1/3 \
TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Maximum operating distance30 m
DC output current0.4 A
DC output voltage12
Power source typeDC, PoE
Power consumption (max)5 W
Power consumption (Power over Ethernet (PoE))7 W
IK codeIK10
Form factorDome
Mounting typeCeiling/wall
Product colorBlack, White
Housing materialMetal, Plastic
International Protection (IP) codeIP67
Pan range0 - 355 °
Tilt angle range0 - 70 °
Camera shutter speed1/3 - 1/100000 s
Minimum illumination0.01 lx
Field of view (FOV) angle117 °
LED typeIR
Infra-red wavelength850 nm
Wi-FiNo
Number of users32 user(s)
Networking standardsIEEE 802.3af
Ethernet interface type10 Gigabit Ethernet, 100 Gigabit Ethernet
Supported network protocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Ethernet LAN (RJ-45) ports1
Operating temperature (T-T)-30 - 50 °C
Weight and Dimensions IconWeight and Dimensions
Width111 mm
Height82.4 mm
Weight410 g
Package weight610 g
