User Manual of E Series Network Mini PTZ camera
© Hikvision
Figure 4-9 Adding Presets
4. Configure the preset number, patrol time and patrol speed.
It is the duration staying on one patrol point. The mini PTZ camera
moves to another patrol point after the patrol time.
It is the speed of moving from one preset to another.
5. Click OK to save a preset into the patrol.
6. Repeat the steps from 3 to 5 to add more presets.
7. Click OK to save all the patrol settings.
Calling a Patrol:
In the PTZ control panel, select a defined patrol from the list and click to call the patrol, as
shown in Figure 4-10.
Figure 4-10 Calling a Preset
