Scheduled-Switch: Switch to the day mode at 6:00 a.m., and switch to the night mode at 18:00
p.m.
(2) Select Area to configure in the dropdown list.
(3) Set the values of Sensitivity.
Sensitivity: The greater the value is, the easier the alarm will be triggered.
5. Set the Arming Schedule for Motion Detection.
(1) Click tab to enter the arming schedule setting interface.
Figure 6-3 Arming Schedule
(2) Select the timeline of a certain day, and drag the mouse to set the arming schedule (the start
time and end time of the arming task).
(3) After you set the scheduled task, you can click and copy the task to other days (optional).
Figure 6-4 Arming Time Schedule
(4) After setting the arming schedule, you can click a segment to display the segment arming
settings interface to edit the segment record parameters (optional).
