Click on the tool bar of the live view panel. Click the mouse on the live view panel. Right click
the mouse to finish drawing.
Figure 6-22 Draw Area
4) Set the duration from 1to 100.
5) Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule.
6) Click to save the settings.
Region Entrance
Purpose:
This function can be used for detecting people, vehicles and objects entering the pre-defined
region. The alarm will be triggered if the rule is broken.
Steps:
1) Create new rule: Click to add a new rule.
2) Select rule type: Click the dropdown list and select Region Entrance as the rule type.
Figure 6-23 Select Rule Type
3) Configure the rule area:
Click on the tool bar of the live view panel. Click the mouse on the live view panel. Right click
the mouse to finish drawing.
