Network Video Recorder User Manual
17
Figure 2-2 Image Settings
2. Select a camera to set image parameters.
3. Adjust the slider, or click on the up/down arrow to set brightness, contrast, or saturation.
4. Set Enable Rotate to Clockwise 270 degrees or OFF. When OFF is selected, the image is
restored to original.
5. Select Mirror ModetoLeft-Right, Up-Down, Center or OFF. When OFF is selected, the image is
restored to original.
Note
● The Rotate and Mirror functions must be supported by the connected IP camera
● The image parameters adjustment can affect both the live view and the recording quality.
6. Click Apply.
2.3 Configure Video Parameters
You can customize the image parameters including the brightness, contrast, saturation, image
rotate and mirror for the live view and recording effect.
Steps
1. Go to Menu → Camera → Image → Image Settings.
To Next Page
