1 2 S E T U P R E C O R D I N G ( c o n t i n u e d )
Motion Detection Recording
Motion Recording will capture video only when motion in the scene is detected.
1. To set MOTION RECORDING, go to MENU > RECORDING CONFIGURATION
2. Click on EVENT under the calendar (yellow) and the mouse cursor will change to a wand.
3. Select the days you wish to set motion recording and they will turn yellow.
4. Press APPLY.
5. Press COPY button to copy the new schedule to the remaining cameras.
6. After recording has been set to Event Recording, go to Motion Detect to set the motion
detection for each camera. In this step, the Copy option is only for analog cameras; IP cameras
need to be configured individually.
7. Go to RECORDING CONFIGURATION > RECORD QUALITY and set the following items:
• Stream Type enables/disables audio streaming from the cameras (if the camera does not
have audio capabilities, Stream Type will have only Video option).
• Resolution sets recording resolution.
• Bitrate Type saves HDD space when set to Variable. Choices: Variable and Constant.
Select camera
ENABLE MOTION DETECTION
Click to enable/disable
MOTION GRID
Draw grid area that will detect
motion
MOTION SENSITIVITY
Selectnumber of green squares to
set sensitivity (in example,
sensitivity is set to 3)
APPLY
Click to apply settings
To Next Page
