HIKVISION DS-7204HI series User Manual

Appendix D Specifications
Model Name DS-7204HI DS-7204HI-V
Video compression
H.264
Preview resolution
PAL: 352*288 (CIF), NTSC: 352*240 (CIF)
Playback resolution
PAL: 352*288 (CIF), NTSC: 352*240 (CIF)
Video input
4-ch BNC (Electrical Level: 1.0Vp-p, resistance: 75Ω)
Composite video
output
1-ch, BNC (Electrical Level: 1.0Vp-p, resistance: 75Ω)
Spot video Output
1-ch, BNC (Electrical Level: 1.0Vp-p, resistance: 75Ω)
Max frame rate
PAL: 25FPS, NTSC: 30FPS
Audio compression
OggVorbis 16Kbps
Audio input
1-ch RCA (Electrical Level: 2.0Vp-p, Resistance: 1000Ω)
Audio output
stance: 600Ω) 1-ch RCA (Linear Electrical Level, Resi
Stream type
Video/Video&Audio
Max bit rate
32Kbps--2Mbps, self-define
HDD IDE interface
1 IDE interface, support 1 IDE HDD (2000GB maximum)
Network interface
1 RJ45 10M/100M Self-adaptive Ethernet Interface
USB interface
1 USB2.0, can support USB memory/HDD, USB CD/DVD burner
VGA interface No
1 VGA interface,
support resolution: 800×600/60Hz,
1024×768/60Hz,
1280 ×1024/60Hz
External alarm in
4
Relay output
1
PTZ control
T+, T-, R+, R-
Voice talk
Same as audio input and audio output
Dual stream
Yes
Power supply
DC 12V
Power consumption
Less than 10W (without HDD)
Working
temperature
-10℃--＋55℃
Working humidity
10％--90％
Size
315mm x 230mm x 45mm
PAL: 176*144(QCIF), 352*288(CIF), 704*288(2CIF), 528*384(DCIF), 704*576(4CIF);
NTSC: 176*120(QCIF), 352*240(CIF), 704*240(2CIF), 528*320(DCIF), 704*480(4CIF).
