HIKVISION DS-7208HGHI-E1 User Manual

Digital Video Recorder User Manual
56
Figure 2-9 Draw the Pattern

Connect at least 4 dots to draw the pattern.

Each dot can be connected for once only.
Step 2 Draw the same pattern again to confirm it. When the two patterns match, the pattern is
configured successfully.
Figure 2-10 Confirm the Pattern
If the two patterns are different, you must set the pattern again.

HIKVISION DS-7208HGHI-E1 Specifications

General

Brand	HIKVISION
Model	DS-7208HGHI-E1
Category	DVR
Language	English
