HIKVISION DS-7216HQHI-F1/N User Manual

Digital Video Recorder User Manual
304
18.1.16 DS-7600HUHI-F/N
Model
DS-7604HUHI-F1/
N
DS-7608HUHI-F2
/N
DS-7616HUHI-F2
/N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD
input
3 MP, 1080p25, 1080p30, 720p60, 720p50, 720p30, 720p25
AHD input 720p30, 720p25, 1080p25, 1080p30
HDCVI input
720p30, 720p25, 1080p25, 1080p30
CVBS input Support
IP video input
4-ch (up to 8-ch) 8-ch (up to 16-ch) 16-ch (up to 32-ch)
Up to 8 MP resolution
Network
Bandwidth
96 Mbps 128 Mbps
144 Mbps
(incoming: 76
Mbps)
Audio
compression
G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704
× 480
HDMI/VGA
output
1-ch, 1920 ×
1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
VGA: 1-ch, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K
(2560 × 1440)/60Hz, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
Encoding
resolution
3MP/1080p/720p/WD1/4CIF/VGA/CIF

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
