HIKVISION DS-7216HQHI-F1/N User Manual

Digital Video Recorder User Manual
305
Model
DS-7604HUHI-F1/
N
DS-7608HUHI-F2
/N
DS-7616HUHI-F2
/N
Frame rate
Main stream:
3MP@15fps;
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 10 Mbps
Audio output 1-ch, RCA (Linear, 1 KΩ)
Audio bit rate 64 Kbps
Dual-stream Support
Stream type Video, Video & Audio
Synchronous
playback
4-ch 8-ch 16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA 1 SATA interface 2 SATA interfaces
Capacity Up to 6 TB capacity for each disk.
External
interface
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
Network
interface
1, RJ45
10M/100Mbps
self-adaptive
Ethernet interface
1, RJ45 10M/100M/1000Mbps
self-adaptive Ethernet interface
USB interface 2 × USB 2.0
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0
Serial
interface
RS-485 (half-duplex)
Alarm in/out 4/1 8/4 16/4

HIKVISION DS-7216HQHI-F1/N Specifications

General

Video input channels	16 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Power consumption (typical)	30 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Analog signal format system	NTSC, PAL
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
