Network Video Recorder User Manual
80
Figure 5-5 People Gathering Detection
4. Check Enable People Gathering Detection.
5. Optional: Check Save VCA Picture to save the captured people gathering detection pictures.
6. Set people gathering detection parameters.
1) Select Arming Area.
Note
Up to 4 areas are selectable.
2) Click Draw Area to draw a quadrilateral in the preview window by specifying four vertices of
the area.
3) Set Percentage.
Percentage
The density of human bodies within the area. If it exceeds the threshold value, the device
will trigger alarm.
7. Set the arming schedule. Refer to Configure Arming Schedule.
8. Set the linkage actions. Refer to Configure Linkage Actions.
9. Click Apply.
5.2.5 Fast Moving Detection
Fast moving detection is used to detect suspicious running and chasing, over-speed, and fast
moving. It will trigger alarm when an object is moving fast and send notification to arming host so
