Network Video Recorder User Manual
135
9.6 Region Exiting Detection
Purpose:
Region exiting detection function detects people, vehicle or other objects which exit from a pre-defined virtual
region, and some certain actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.5 Region Entrance Detection for operating steps to configure the region exiting
detection.
 Up to 4 rules can be configured.
9.7 Loitering Detection
Purpose:
Loitering detection function detects people, vehicle or other objects which loiter in a pre-defined virtual region for
some certain time, and a series of actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the loitering detection.
 The Threshold [1s-10s] in the Rule Settings defines the time of the object loitering in the region. If you set
the value as 5, alarm is triggered after the object loitering in the region for 5s; and if you set the value as 0,
alarm is triggered immediately after the object entering the region.
 Up to 4 rules can be configured.
9.8 People Gathering Detection
Purpose:
People gathering detection alarm is triggered when people gather around in a pre-defined virtual region, and a
series of actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the people gathering
detection.
 The Percentage in the Rule Settings defines the gathering density of the people in the region. Usually, when
the percentage is small, the alarm can be triggered when small number of people gathered in the defined
detection region.
 Up to 4 rules can be configured.
9.9 Fast Moving Detection
Purpose:
Fast moving detection alarm is triggered when people, vehicle or other objects move fast in a pre-defined virtual
region, and a series of actions can be taken when the alarm is triggered.

HIKVISION DS-96128NI-I16 Specifications

General

Audio system	2-way
Input bandwidth	576 Mbit/s
Output bandwidth	512 Mbit/s
Maximum frame rate	30 fps
Maximum resolution	4096 x 2160 pixels
Alarm input channels	16
Video input channels	128 channels
Alarm output channels	8
Supported resolutions	4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
RAID support	Yes
HDD interface	SATA
Maximum storage capacity	160 TB
Number of HDDs installed	0
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Wi-Fi	No
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	140 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Display type	LCD
Display diagonal	7 \

Weight and Dimensions

Depth	494 mm
Width	442 mm
Height	146 mm
Weight	16000 g
