Network Video Recorder User Manual
153
Figure 11. 10 Access Device via iVMS4200
5. Click the Apply button to save and exit the interface.
11.2.2 Configuring NTP Server
Purpose:
A Network Time Protocol (NTP) Server can be configured on your NVR to ensure the accuracy of system
date/time.
Steps:
1. Enter the Network Settings interface.
Menu >Configuration> Network
2. Select the NTP tab to enter the NTP Settings interface, as shown in Figure 11. 11.
Figure 11. 11 NTP Settings Interface
3. Check the Enable NTP checkbox to enable this feature.
4. Configure the following NTP settings:
Interval: Time interval between the two synchronizing actions with NTP server. The unit is minute.
NTP Server: IP address of NTP server.
NTP Port: Port of NTP server.
5. Click the Apply button to save and exit the interface.
The time synchronization interval can be set from1 to 10080min, and the default value is 60min. If the NVR is
connected to a public network, you should use a NTP server that has a time synchronization function, such as the
server at the National Time Center (IP Address: 210.72.145.44). If the NVR is setup in a more customized network,
NTP software can be used to establish a NTP server used for time synchronization.

Table of Contents

Other manuals for HIKVISION DS-96128NI-I16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-96128NI-I16 and is the answer not in the manual?

HIKVISION DS-96128NI-I16 Specifications

General IconGeneral
Audio system2-way
Input bandwidth576 Mbit/s
Output bandwidth512 Mbit/s
Maximum frame rate30 fps
Maximum resolution4096 x 2160 pixels
Alarm input channels16
Video input channels128 channels
Alarm output channels8
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
RAID levels0, 1, 5, 6, 10
HDD capacity- GB
RAID supportYes
HDD interfaceSATA
Maximum storage capacity160 TB
Number of HDDs installed0
eSATA ports quantity1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports4
Supported network protocolsIPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Wi-FiNo
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)140 W
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack
Display typeLCD
Display diagonal7 \
Weight and Dimensions IconWeight and Dimensions
Depth494 mm
Width442 mm
Height146 mm
Weight16000 g
