Network Video Recorder User Manual
152
Figure 11. 9 Register the Device
4) Input Device Serial No., Device Domain (Device Name) and HTTP Port. And click OK to
add the device.
 Access the Device via Web Browser or Client Software
After having successfully registered the device on the HiDDNS server, you can access your device
via web browser or Client Software with the Device Domain (Device Name).
 OPTION 1: Access the Device via Web Browser
Open a web browser, and enter http://www.hik-online.com/alias in the address bar. Alias refers to
the Device Domain on the device or the Device Name on the HiDDNS server.
Example: http://www.hik-online.com/nvr
If you mapped the HTTP port on your router and changed it to port No. except 80, you have to
enter http://www.hik-online.com/alias:HTTP port in the address bar to access the device. You can
refer to Chapter 9.2.11 for the mapped HTTP port No..
 OPTION 2: Access the devices via iVMS4200
For iVMS-4200, in the Add Device window, select and then edit the device
information.
Nickname: Edit a name for the device as you want.
Server Address: www.hik-online.com
Device Domain Name: It refers to the Device Domain Name on the device or the Device Name
on the HiDDNS server you created.
User Name: Enter the user name of the device.
Password: Enter the password of the device.

HIKVISION DS-96128NI-I16 Specifications

General

Audio system	2-way
Input bandwidth	576 Mbit/s
Output bandwidth	512 Mbit/s
Maximum frame rate	30 fps
Maximum resolution	4096 x 2160 pixels
Alarm input channels	16
Video input channels	128 channels
Alarm output channels	8
Supported resolutions	4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
RAID support	Yes
HDD interface	SATA
Maximum storage capacity	160 TB
Number of HDDs installed	0
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	4
Supported network protocols	IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Wi-Fi	No
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	140 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Display type	LCD
Display diagonal	7 \

Weight and Dimensions

Depth	494 mm
Width	442 mm
Height	146 mm
Weight	16000 g
