Network Video Recorder User Manual
66
5.2 Configuring Recording Schedule
Purpose:
Set the record schedule, and then the camera automatically starts/stops recording according to the configured
schedule.
In this chapter, we take the record schedule procedure as an example, and the same procedure can be applied to
configure schedule for both recording and capture. To schedule the automatic capture, you need to choose the
Capture tab in the Schedule interface.
Steps:
1. Enter the Record Schedule interface.
Menu > Record > Schedule
2. Configure Record Schedule
1) Select Record Schedule.
Figure 5. 6 Record Schedule
Different recording types are marked in different color icons.
Continuous: scheduled recording.
Event: recording triggered by all event triggered alarm.
Motion: recording triggered by motion detection.
Alarm: recording triggered by alarm.
M/A: recording triggered by either motion detection or alarm.
M&A: recording triggered by motion detection and alarm.
You can delete the set schedule by clicking the None icon.
2) Choose the camera you want to configure.
3) Select the check box after the Enable Schedule item.

Table of Contents

Other manuals for HIKVISION DS-96128NI-I16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-96128NI-I16 and is the answer not in the manual?

HIKVISION DS-96128NI-I16 Specifications

General IconGeneral
Audio system2-way
Input bandwidth576 Mbit/s
Output bandwidth512 Mbit/s
Maximum frame rate30 fps
Maximum resolution4096 x 2160 pixels
Alarm input channels16
Video input channels128 channels
Alarm output channels8
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
RAID levels0, 1, 5, 6, 10
HDD capacity- GB
RAID supportYes
HDD interfaceSATA
Maximum storage capacity160 TB
Number of HDDs installed0
eSATA ports quantity1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports4
Supported network protocolsIPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
Wi-FiNo
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)140 W
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack
Display typeLCD
Display diagonal7 \
Weight and Dimensions IconWeight and Dimensions
Depth494 mm
Width442 mm
Height146 mm
Weight16000 g
