Quick Operation Guide of DS-A81 Series Storage System
24
Figure 5. 7 Create LUN
3) Input the LUN name, LUN size in the text fields and select the block size from the
drop-down list.
4) Check the checkbox to select a physical volume on which the LUN is created.
5) Click OK to confirm the settings.
At least 5 LUNs are required for the CVR service, of which 4 LUNs with capacity over 20GB
need to be set as private volumes and the corresponding spare volumes, and other LUNs
need to be set as record volumes.
3. Create the private volumes.
1) Enter the Private Volume Settings interface, and the free LUNs in the system are
displayed on the Free LUN list.
CVR > CVR > CVR config > Set private volume
Figure 5. 8 Create Private Volume
2) Select the free LUN from the list and then click or
