HIKVISION DS-C30S-S23 Quick Start Guide

Video Wall Controller • Quick Start Guide
16
Connect the Grounding Cable to the Grounding Row
Without Grounding Row
Drive an angle steel (4) or steel pipe into the ground (3) of at least 0.5 m.
Weld one end of the grounding cable (2) to the angle steel or steel pipe and treat the
welding points with corrosion protection (electroplate or coating).
Connect the other end of the grounding cable to a grounding terminal (1) of the device.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
