HIKVISION DS-K1T501SF User Manual

Video Access Control Terminal·User Manual
105
Table 7-1 Live View and Playback Parameters
Parameters
Description
Picture Format
Set the file format for the captured pictures during live view or
playback.
Merge Downloaded
Video Files
San set the maximum size of merged video file for downloading
the video file by date.
Search Video Files
Stored in
Set to search the video files stored in the local device, in the
storage server, or both in the storage server and local device for
playback.
Pre-play for
Set the pre-play time for event playback.
Note: You should set it as None to check the live view and the
playback.
Enable Screen
Toolbar Display
Show the toolbar on each display window in live view or
playback.
Prioritize Playback
of Video Files on
Storage Server
Play back the video files recorded on the storage server
preferentially.
Otherwise, play back the video files recorded on the local
device.
Resume Latest Live
View Status After
Restart
Resume the latest live view status after you log into the client
again.
Disconnect
Background Videos
In multiple-window division mode, double-click a live video to
display it in 1-window division mode, and the other live videos

HIKVISION DS-K1T501SF Specifications

General

Type	Basic access control reader
Product color	Gray
Cards capacity	50000 cards
Housing material	Metal
Keypad integrated	No
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Face recognition
Transaction capacity	200000
Fingerprint sensor type	Optical
Identification (1:N) time	1.5 s
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
DC current (max)	600 A
DC voltage range	12 V
Total megapixels	2 MP
Front camera type	Single camera
PC connected	-
RS-485 ports	1
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	218 mm
Width	78 mm
Height	41 mm
