HIKVISION DS-K1T501SF User Manual

Video Access Control Terminal·User Manual
121
7.16.2 Normal Playback
Purpose:
The video files stored on the local device or the storage server can be searched by camera or
triggering event, and then can be played back remotely.
Before you start:
You can set to play back the video files stored in the local device, in the storage server, or both in
the storage server and local device. For details, refer to 8.5.1 Storing on Storage Device.
Optionally, you can set the cameras rotate direction for playback in Group Management. Refer to
Editing the Group/Camera of Chapter 8.3 Group Management.
Click the icon on the control panel,
or click View->Remote Playback to open the Remote Playback page.
Remote Playback Page
1 Camera List
2 Display Window of Playback
3 Playback Control Buttons
4 Timeline
5 Calendars
6 Search Condition
Switching Video Stream for Playback
Purpose:
Optionally, you can switch between main stream and sub-stream for playback.
Before you start:
Set the video stream for recording as Dual-Stream.

HIKVISION DS-K1T501SF Specifications

General

Type	Basic access control reader
Product color	Gray
Cards capacity	50000 cards
Housing material	Metal
Keypad integrated	No
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Face recognition
Transaction capacity	200000
Fingerprint sensor type	Optical
Identification (1:N) time	1.5 s
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
DC current (max)	600 A
DC voltage range	12 V
Total megapixels	2 MP
Front camera type	Single camera
PC connected	-
RS-485 ports	1
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	218 mm
Width	78 mm
Height	41 mm
