HIKVISION DS-K1T501SF User Manual

Video Access Control Terminal·User Manual
120
Configuring Storage Schedule
Before you start:
The storage server needs to be added to the client software and the HDDs need to be formatted
for the video file storage.
Steps:
1. Open the Storage Schedule page.
2. Select the camera from the Camera Group list.
3. Select the storage server from the Storage Server drop-down list.
Note: You can click Storage Server Management to add, edit or delete the storage server.
4. Check the checkbox Recording Schedule to enable storing the video files.
You can also check the checkbox Picture Storage to store the alarm pictures of the camera
when event occurs.
For the network cameras with the function of heat map or people counting, the Additional
Information Storage checkbox is available. You can click VCA Config to set the VCA rule for the
camera, and check the Additional Information Storage checkbox and the heat map, people
counting data and road traffic data will be uploaded to the storage server.
Note: For detailed configuration about setting the VCA rule, please refer to the User Manual of
the camera.
5. Select the schedule template for recording from the drop-down list.
If you need to edit or customize the template, see Configuring Recording Schedule Template.
6. Click Advanced Settings to set the pre-record time, post-record time and other parameters for
recording.
7. Click Set Quota to enter the HDD management interface of the storage server. You can set the
corresponding quota ratio for record, picture and additional information.
Example: If you set the record quota as 60%, then the 60% of the storage space can be used for
storing the video files.
8. Click Save to save the settings.
Note: The storage server supports storage of line crossing detection alarm, intrusion detection
alarm, region entrance detection alarm, region exiting detection alarm, fast moving detection
alarm, people gathering detection alarm, loitering detection alarm, parking detection alarm, object
removal detection alarm, and unattended baggage detection alarm recording.

HIKVISION DS-K1T501SF Specifications

General

Type	Basic access control reader
Product color	Gray
Cards capacity	50000 cards
Housing material	Metal
Keypad integrated	No
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Face recognition
Transaction capacity	200000
Fingerprint sensor type	Optical
Identification (1:N) time	1.5 s
False Rejection Rate (FRR)	0.01 %
False Acceptance Rate (FAR)	0.001 %
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
DC current (max)	600 A
DC voltage range	12 V
Total megapixels	2 MP
Front camera type	Single camera
PC connected	-
RS-485 ports	1
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	218 mm
Width	78 mm
Height	41 mm
