Face Recognition Terminal User Manual
11
Chapter 3 Installation
Installation Environment:
Install the device indoors, at least 2 meters away from the light, and at least 3 meters away
from the window or the door.
Make sure the environment illumination is more than 100Lux.
Note: For details about installation environment, see Appendix B Tips for Installation Environment.
Installation Types: Wall mounting with gang box and wall mounting without gang box.
3.1 Installing with Gang Box
Steps:
1. According to the datum line on the mounting template, stick the mounting template on the wall
or other surface, 1.4 meters higher than the ground.
2. Drill holes on the wall or other surface according to the mounting template and install the gang
box (80mm×80mm).
3. Use two supplied screws to secure the mounting plate on the gang box.
4. Use another four supplied screws to secure the mounting plate on the wall.
To Next Page
