Figure 3-2 Mounng Plate Dimension
2.
Remove the back panel to display the wiring area. Wire the cables and install the back panel
back.
Figure 3-3 Remove Back Panel
Note
Apply Silicone sealant among the cable wiring area to keep the raindrop from entering.
Access Control Terminal User Manual
5
