Chapter 4 Device Wiring
4.1 External Device Wiring
Wire the external device.
The wiring diagram is as follows.
Figure 4-1 External Device Wiring
Note
●
When connecng door contact and exit buon, the device and the RS-485 card reader should
use the same common ground connecon.
●
You should set the face recognion terminal's Wiegand direcon as Input to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand
direcon as
Output to transmit
authencaon informaon to the access controller.
●
For details about Wiegand direcon sengs, see Set Wiegand Parameters .
●
The device and the door lock should use separate power supply.
