Figure 2-2 Appearance and Interfaces of 1-Door Access Controller Main Board
Appearance and Interfaces of 2-Door Access Controller
Note
●
Only paral models support Wi-Fi and POE funcon.
●
PoE model devices need to be aware of the following:
1. The switch specicaon is 30 W.
2. PoE and Wi-Fi
funcon cannot be used at the same me.
3. If the total power of the incoming locks exceeds 10 W, an addional separate power supply is
required for one of the locks.
4. Supports access to up to 4 card readers.
DS-K27XX Series Access Controller User Manual
3
