HIKVISION DS-K27 Series User Manual

Chapter 7 Typical Applicaon
The typical applicaon for access controller, access module, lock and plaorm is as follows.
Figure 7-1 Typical Applicaon
1
No RS-485 redundant protecon max. 128 doors.
Note
The DS-K2704X series support up to 128 doors; K2702X series support up to 126 doors;
K2701x series support up to 125 doors.
2 With RS-485 redundant protecon max. 64 doors.
3 Max. 4 doors.
DS-K27XX Series Access Controller User Manual
27
