3.
Set the network parameters.
-
Enable DHCP, and the system can assign an IP address of the indoor staon
automacally.
-
Disable the DHCP funcon, and set the IP address manually. You should set
the device IP address, the gateway, the DNS address.
2.3.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door
staon, doorphone, main staon, center, etc.), to which the indoor staon is linked.
Linked devices for the indoor
staon refers to door staon, center, main staon, and
doorphone.
With the private SIP protocol, intercom can be realized only when all these devices
are in the same network segment with the indoor staon.
With the standard SIP protocol, intercom can be realized when all these devices
support the standard SIP protocol.
Steps
Note
•
The doorphone does not support adding with the standard SIP protocol.
•
Here take door staon network sengs as example.
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap to enter the device management page.
3.
Tap Indoor Extension and select a connect indoor extension.
4.
Tap Main Door Staon to pop up the device informaon dialog.
Video Intercom Indoor
Staon Conguraon Guide
7

HIKVISION DS-KH6320-WTE2 Specifications

General

Color	Yes
Speakerphone	-
Connectivity technology	Wireless
Voice codecs	G.711u
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Product color	Black, Grey
Operating system installed	Linux
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Supported network protocols	TCP/IP, SIP, RTSP
Outdoor unit included	No
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	6 W

Weight and Dimensions

Depth	15.1 mm
Width	200 mm
Height	140 mm
