HIKVISION DS-PHA48-EP User Manual

26
3. Click to enter the Sounder Settings page.
3. Set the sounder name and alarm duration.
4. Check the linked area.
Note
 Only enabled areas will be listed.
 The newly added peripheral is linked to area 1 by default.
5. Check the link event.
6. Enable Sounder Tamper Alarm.
7. Click OK.
Note
After the sounder is configured, you can click Maintenance → Device Status → Sounder Status
to view the sounder status.
Keypad
You can set the parameters of the keypad that is enrolled to the AX HYBRID PRO .
Steps
1. Click Device → Keypad to enter the page.
2. Click to enter the Keypad Settings page.

HIKVISION DS-PHA48-EP Specifications

General

2G standards	GSM
Number of alarm zones	48
Alert notification type	SMS
Connectivity technology	Wired & Wireless
Mobile network generation	4G
Smartphone remote support	Yes
Number of simultaneous users	48 user(s)
Control type	-
Mounting type	Wall
Product color	White
Housing material	Plastic
Number of door/window sensors	- pc(s)
Battery life	36 h
Input voltage	100 - 240 V
Battery voltage	13.5 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	996.5 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 261 mm
