HIKVISION DS-PHA64-LP User Manual

52
Note
Only when all the detectors are without fault, you can enter the mode TEST mode.
2. Enable Test to start walk test.
3. Click Save to complete the settings.
4. Trigger the detector in each zone.
5. Check the test result.
System Maintenance
You can reboot the device, restore default settings, import/export configuration file.
Select the device and click in the client software, or enter the device IP address in the address
bar of the web browser. Click Maintenance→ Device Maintenance→ Maintenance to enter the
page.

HIKVISION DS-PHA64-LP Specifications

General

Wi-Fi	Yes
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of alarm zones	64
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	-10 - 40 °C
Number of simultaneous users	62 user(s)
Operating relative humidity (H-H)	10 - 90 %
Number of simultaneously connected devices (max)	-
Batteries included	No
Number of door/window sensors	- pc(s)
Mounting type	Wall
Product color	White
Housing material	Plastic
Battery life	36 h
Alarm current	2000 mA
Input voltage	100 - 240 V
Battery voltage	12 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	997 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 199 mm
