HIKVISION DS-PHA64-LP User Manual

67
2. Tap → System → System Options → System Fault Check to enter the page.
Detect Network Camera Disconnection
If the option is enabled, when the linked network camera is disconnected, an alarm will be
triggered. The delay time of network camera disconnection detection is the same as that of
LAN.
Panel Battery Fault Check
If the option is enabled, when panel battery is disconnected or in low battery status, the device
will upload events.
LAN Lost
If the option is enabled, when the wired network is disconnected or with other faults, the alarm
will be triggered.
WiFi Lost
If the option is enabled, when the Wi-Fi is disconnected or with other faults, the alarm will be
triggered.
Cellular Lost
If the option is enabled, when the cellular data network is disconnected or with other faults, the
alarm will be triggered.
Panel Mains Power Lost
If the option is enabled, an alarm will be triggered when the control panel main supply is
disconnected.
Panel Mains Power Loss Delay
The system checks the fault after the configured time duration after AC power down.
To compliant the EN 50131-3, the check time duration should be 10 s.
3.2.11 Arm Options
This function is for the whole alarm system, to inform the user of the current system status before
arming. If it is enabled, there will be a fault prompt and confirmation process for keypads, keyfobs,
and APP. If it is not enabled, there will be no fault detection before arming.
Steps
1. On the device list page, tap the AX HYBRID PRO and then log in to the device (if required) to
enter the page.
2. Tap → System → System Options → Arm Options to enter the page.
You can set the following parameters:
Arm with Fault
Check the faults in the Enable Arming with Fault list, and the device will not stop the arming
procedure when faults occurred.

HIKVISION DS-PHA64-LP Specifications

General

Wi-Fi	Yes
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of alarm zones	64
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	-10 - 40 °C
Number of simultaneous users	62 user(s)
Operating relative humidity (H-H)	10 - 90 %
Number of simultaneously connected devices (max)	-
Batteries included	No
Number of door/window sensors	- pc(s)
Mounting type	Wall
Product color	White
Housing material	Plastic
Battery life	36 h
Alarm current	2000 mA
Input voltage	100 - 240 V
Battery voltage	12 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	997 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 199 mm
