HIKVISION DS-PHA64-LP User Manual

79
– Tap to enter the Manually Input page. Enter the device serial No. and select the device
type to add the device.
3.3.4 Main Page
You can view faults, arm and disarm areas, view device status, etc.
On the device list page, tap the AX HYBRID PRO and then log in to the device (if required) to enter
the page.
Enable Alarm
Tap to select Audible Panic Alarm or Silent Panic Alarm.
View Faults
Tap to view faults.
Area Management
Tap + to add an area.
Tap Area to enter the area management page. Refers to 3.2.15 Set Arming/Disarming

HIKVISION DS-PHA64-LP Specifications

General

Wi-Fi	Yes
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of alarm zones	64
Connectivity technology	Wired & Wireless
Operating temperature (T-T)	-10 - 40 °C
Number of simultaneous users	62 user(s)
Operating relative humidity (H-H)	10 - 90 %
Number of simultaneously connected devices (max)	-
Batteries included	No
Number of door/window sensors	- pc(s)
Mounting type	Wall
Product color	White
Housing material	Plastic
Battery life	36 h
Alarm current	2000 mA
Input voltage	100 - 240 V
Battery voltage	12 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	997 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 199 mm
