HIKVISION HWD Series User Manual

Digital Video Recorder User Manual
34
status. If the camera is in inactive status, you can click the inactive icon of the camera to set
the password to activate it. You can also select multiple cameras from the list and click the
One-touch Activate to activate the cameras in batch.
2) Click the Add to add the camera.
3) (Optional) Check the checkbox of Enable H.265 (For Initial Access) for the connected IP
camera supporting H.265. Then the IP camera will be encoded with H.265.
Figure 2-23 IP Camera Management
Step 7 After finishing IP Camera settings, click Next to enter the Record Settings interface.
Step 8 Click , and you can enable the continuous recording or motion detection recording for
all channels of the device.
Figure 2-24 Record Settings
Step 9 Click OK to complete the wizard settings.

HIKVISION HWD Series Specifications

General

Operating System	Embedded Linux
Video Compression	H.264, H.265
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel
Network Interface	1 RJ45 10M/100M Self-Adaptive Ethernet Interface
USB Interface	2 USB 2.0
HDD Interface	SATA
Power Supply	12 VDC
Mobile Access	Hik-Connect
Encoding Resolution	1080p, 720p, VGA, WD1, 4CIF, CIF
