Digital Video Recorder User Manual

Figure 5-20 VCA Settings

Step 2 Select a Camera.

Step 3 Configure the detection rules for VCA events. For details, see the step 6 in Chapter 10.3

Line Crossing Detection.

Step 4 Click the icon to configure the alarm linkage actions for the VCA events.

Select Trigger Channel tab and select one or more channels which will start to record when

VCA alarm is triggered.

Step 5 Click Apply to save the settings.

Figure 5-21 Set Triggered Camera of VCA Alarm

Step 6 Enter Record Schedule Settings interface (Menu> Record> Schedule>Record Schedule),

and then set Event as the record type. For details, see step 2 in Chapter 5.2 Configuring

Recording and Capture Schedule.

Questions and Answers:

Need help?

Do you have a question about the HIKVISION HWD Series and is the answer not in the manual?

General

Operating System	Embedded Linux
Video Compression	H.264, H.265
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel
Network Interface	1 RJ45 10M/100M Self-Adaptive Ethernet Interface
USB Interface	2 USB 2.0
HDD Interface	SATA
Power Supply	12 VDC
Mobile Access	Hik-Connect
Encoding Resolution	1080p, 720p, VGA, WD1, 4CIF, CIF
