Network Video Recorder User Manual
28
3.4 Configure Live View Layout
Live view displays the video image getting from each camera in real time.
3.4.1 Configure Custom Live View Layout
Steps
1. Go to System → Live View → View.
2. Click Set Custom Layout.
3. Click on the Custom Layout Configuration interface.
4. Edit the layout name.
5. Select a window division mode from the toolbar.
Figure 3-3 Configure Live View Layout
6. Select multiple windows and click to joint the windows. The selected windows must be in
rectangle area.
7. Click Save.
The successfully configured layout is displayed in the list.
8. Optional: Select a live view layout from the list and click to edit the name, or click to
delete the name.
