8.5 Detecting VCA Alarm
Purpose:
The NVR can receive the VCA alarm sent by IP camera, and the VCA detection must be enabled and configured
on the IP camera settings interface first. Refer to the user manual of IP camera for detailed instructions to set the
VCA rules.
Steps:
1. Enter VCA Alarm interface of Camera Management and select a camera you want to detect VCA alarm.
Menu> Camera> VCA
The selected camera must support the VCA function.
Figure 8. 13 VCA Alarm Setting Interface
2. Check the Enable VCA Alarm checkbox and click Settings button to set up its alarm response actions.
3. Select Trigger Channel tab and select one or more channels which will start to record/capture or become
full-screen monitoring when a VCA alarm is triggered, and click Apply to save the settings.
4. Select Arming Schedule tab to set the arming schedule of handling actions.
Figure 8. 14 Set Arming Schedule of VCA Alarm
Choose one day of a week and Max. eight time periods can be set within each day, and click Apply to save
the settings.
