HIKVISION PanoVu Series Quick Start Guide

PanoVu Series Camera·Quick Start Guide
15
Head Cover
Camera
Main Body
Figure 1-19 Head Cover of PanoVu Camera
5. Install the head cover of PanoVu camera.
1) Loosen the two lock screws and make sure that the screws do not appear in the inner side of
bracket, as shown in Figure 1-20.
2) Route the cables through the head cover and insert the head cover into the bottom of the
bracket.
3) Fix the head cover with the bracket by rotating the head cover clockwise or anticlockwise.
4) Fix two lock screws with the Allen wrench to secure the camera.
Lock Screws
Figure 1-20 Installing Head Cover of PanoVu Camera
6. After fixing the head cover, hook the two ends of the safety rope to the bracket and the
camera respectively, as shown in Figure 1-21.
VIEOD
Safety Rope
Figure 1-21 Install the Safety Rope
