English 11
3.3 Recommendations for use
We recommend:
• Use of the wet cutting method is preferable in order to reduce the amount of dust produced when cutting.
By using the self-priming water pump (accessory) you can work without need for a water supply pipe.
The water can be drawn, for example, directly from a container.
• Do not cut right through the workpiece in one pass. Move the saw back and forward several times until
it gradually reaches the desired cutting depth.
• To avoid damaging the diamond cutting disc when dry cutting, lift the disc out of the cut for approx. 10
seconds every 30 to 60 seconds while the product is still running.
• Resharpen polished diamond segments (no diamonds project from the segment matrix) by cutting with
the disc in a very abrasive material such as sandstone.
• For extensive floor sawing applications, mount the saw on the trolley (accessory).
3.4 Cutting disc specifications
Diamond discs in accordance with EN 13236 are to be used with the product. Synthetic resin-bonded, fiber-
reinforced cutting discs in accordance with EN 12413 (straight, not dish-shaped, type 41) may also be used
with the product for working on metals.
The disc mounting instructions and instructions for use issued by the cutting disc manufacturer must be
observed.
3.5 Items supplied
Gasoline-powered saw, DSH tool set, DSH consumables set (only with the DSH 700-X/900-X), operating
instructions.
You can find other system products approved for your product at your local Hilti Center or online at:
www.hilti.com
3.6 Consumables and wearing parts
• Air filter
• Cord (5 pcs)
• Starter
• Fuel filter
• Spark plug
• Tool set
• Cylinder set
• Mounting screw assy.
• Flange (2)
• Centering ring 20 mm / 1"
4 Technical data
4.1 Gasoline-powered cut-off saw
DSH 700 30/12" /
DSH 700-X 30/12"
DSH 700 35/14" /
DSH 700-X 35/14"
Cubic capacity
68.7 cm³ 68.7 cm³
Weight without cutting disc, fuel tank empty
11.6 kg 11.9 kg
Weight with saw trolley, without cutting disc, fuel
tank empty
42.6 kg 42.9 kg
Rated power at 7500 rpm in accordance with
ISO 7293
3.5 kW 3.5 kW
Maximum spindle speed
5,100 /min 5,100 /min
Max. rotational speed of the cutting disc
5,100 /min 5,100 /min
Maximum cutting depth
100 mm 125 mm
Printed: 24.04.2018 | Doc-Nr: PUB / 5265931 / 000 / 02
