Hilti DSH 700 - Technical data; Gasoline-powered cut-off saw

12 English
DSH 900 35/14" /
DSH 900-X 35/14"
DSH 900 40/16" /
DSH 900-X 40/16"
Cubic capacity
87 cm³ 87 cm³
Weight without cutting disc, fuel tank empty
12.0 kg 12.4 kg
Weight with saw trolley, without cutting disc, fuel
tank empty
43.0 kg 43.4 kg
Rated power at 7500 rpm in accordance with
ISO 7293
4.3 kW 4.3 kW
Maximum spindle speed
5,100 /min 4,700 /min
Max. rotational speed of the cutting disc
5,100 /min 4,700 /min
Maximum cutting depth
125 mm 150 mm
4.2 Additional technical data
Engine type
Single-cylinder, air-cooled two-stroke engine
Maximum engine speed
9500 ± 200 /min
Idling speed
2750 ± 250 /min
Ignition (type)
Electronically-controlled ignition timing
Electrode gap
0.5 mm
Spark plug
Manufacturer: NGK, type: CMR7A-5
Tightening torque for fitting the spark plug
12 Nm
DSH 700/900 carburetor
Manufacturer: Walbro; model: WT; type: 895
DSH 700-X/900-X carburetor
Manufacturer: Walbro; model: WT; type: 1152
Fuel mixture
API-TC oil 2% (1:50)
Tank capacity
900 cm³
Cutting disc arbor size / diameter of centering
bush
20 mm
Cutting disc arbor size / diameter of centering
bush
25.4 mm
Minimum flange outside diameter
102 mm
Max. disc thickness (steel disc thickness)
5.5 mm
Tightening torque for fitting the cutting disc
25 Nm
4.3 Noise information and vibration values determined in accordance with ISO 19432
The sound pressure and vibration values given in these instructions have been measured in accordance with
a standardized test and may be used to compare one gasoline-powered saw with another. They may be
used for a preliminary assessment of exposure.
The data given represents the main applications of the machine. However, if the machine is used for different
applications, with different accessory tools or is poorly maintained, the data may vary. This may significantly
increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the machine is switched
off, or when it is running but not actually being used for a job. This may significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: Maintaining the machine and accessory tools, keeping the hands warm and organizing work
patterns.
Noise emission values
DSH 700 30/12" /
DSH 700-X 30/12"
DSH 700 35/14" /
DSH 700-X 35/14"
Sound pressure level, ISO 19432 (ISO 11201)
(L
pa,eq
)
99 dB(A) 99 dB(A)
Uncertainty
2.8 dB(A) 2.8 dB(A)
Printed: 24.04.2018 | Doc-Nr: PUB / 5265931 / 000 / 02
