20 English
▶ If the following conditions are met, also take this action:
Conditions: The engine is hot.
▶ Pull the choke lever upwards and then push it back down again.
◁ This engages half throttle. The choke is not engaged.
▶ Check that the cutting disc is free to rotate.
▶ Position your right foot over the lower part of the rear grip.
▶ Pull the starter handle slowly with your right hand until resistance is felt.
▶ Pull the starter handle vigorously.
▶ When the motor fires for the first time (after 2 to 5 pulls of the starter), move the choke lever back
down to its original position.
▶ Pull the starter handle vigorously and repeat this action until the engine starts.
The motor will flood if the starting procedure is repeated too many times with the choke
engaged.
▶ Press the throttle trigger briefly as soon as the engine starts.
◁ This disengages the half-throttle position and the engine then runs at idling speed when the
throttle is released.
2. If the following equipment exists, also take this action:
DSH 700-X
DSH 900-X
▶ Press the decompression valve (once).
▶ When starting the cold engine (only when cold), squeeze the primer bulb 2 to 3 times (until the primer
bulb is completely filled with fuel).
▶ Press the throttle safety grip and keep it pressed.
▶ Press the throttle trigger and keep it pressed.
▶ Move the start/stop switch to the “start” position.
▶ Release the throttle safety grip and throttle trigger.
◁ This half-throttle position is activated.
▶ Check that the cutting disc is free to rotate.
▶ Position your right foot over the lower part of the rear grip.
▶ Pull the starter handle slowly with your right hand until resistance is felt.
▶ Pull the starter handle vigorously.
▶ Repeat this action until the engine starts.
▶ Press the throttle trigger briefly as soon as the engine starts.
◁ This disengages the half-throttle position and the engine then runs at idling speed when the
throttle is released.
6.2 Checks after starting the engine
1. Check that the cutting disc remains stationary when the engine is idling and, after briefly running at full
speed, that the disc again comes to a complete standstill.
◁ Readjust (reduce) the idling speed if the cutting disc doesn’t stop rotating when the engine is idling.
If this is not possible, please bring the product to Hilti Service.
