Hilti SCW 22-A User Manual

3. Slide the rip fence guide under the clamping
screw.
4. Set the desired cutting width.
5. Tighten the clamping screw.
7.7 Using the saw on the guide rail 7
7.7.1 Fitting the guide rail adapter 8
NOTE
The saw can be equipped with a guide rail adapter
which is available as an accessory.
1. Remove the rip fence, if one is fitted.
2. Fit the base plate into the side retaining channels
of the guide rail adapter.
3. Fully insert the base plate into the guide rail
adapter.
4. Lock the guide rail adapter by pressing in the
two sliders as far as they will go.
7.7.2 Longitudinal cuts at 0 °
Place the saw on the guide rail so that the rib fits into
the groove in the adapter.
7.7.3 Longitudinal cuts at up to 50 °
Guide the saw so that the outer edge of the guide rail
adapter runs along the rib on the guide rail. The saw
blade will otherwise come into contact with the guide
rail.
7.7.4 Cuts at an angle across the surface of the
workpiece
NOTE
The cutting angle indicated is the angle of deviation
from a straight, right-angled cut.
1. Position the guide rail with the zero mark at the
edge of the workpiece and then pivot the rail until
the desired angle shown on the angle scale is
opposite the zero mark.
2. Use the two screw clamps to secure the guide
rail.
7.8 Using the saw with a dust and chip removal
system 9
NOTE
The circular saw is equipped with a removable con-
nector for a vacuum cleaner / dust removal hose. This
connector is designed to fit standard suction hoses.
CAUTION
Dusts are hazardous to the health and can cause
respiratory or skin diseases and allergic reactions.
WARNING
Certain dusts are considered to be carcinogenic
(cause cancer). These include mineral dust as well as
oak and/or beech wood dust, particularly in conjunc-
tion with additional substances used for the treatment
of wood (chromate, wood preservatives).
CAUTION
As far as possible, use a suitable Hilti sawdust
extractor/deduster, whatever the application. Use
a respiratory protector of the P2 filter class with
half-mask facepiece if no dust removal system is
available or its use is impossible. In addition, to
keep the concentration of dust low, always ensure
good ventilation.
CAUTION
Commercial and industrial users must consult the
responsible trade association to clarify the situation
regarding special requirements applicable to working
on other materials.
7.9 Using the saw without a dust and chip
removal system
The special design of the hose connector prevents
blockage when working without a vacuum cleaner
connected. The sawdust is then guided away to the
side.
Check that the sawdust is ejected without obstruction.
If required, the hose connector can be removed from
the blade guard after releasing the hex. socket screw
using the wrench supplied (located on the power
tool).
7.10 Procedure when sawdust channel is
blocked
1. Pull the battery out of the tool.
2. Clean the sawdust channel.
3. Check for misalignment or binding of moving
parts, breakage of parts and any other condition
that may affect the power tool’s operation.
en
30

Hilti SCW 22-A Specifications

General

Blade diameter	165 mm
Idle speed (max)	4000 RPM
Cutting depth (45º)	42 mm
Cutting depth (90º)	57 mm
Sound pressure level	93 dB
Vibration level (wood cutting)	1.2 m/s²
Product color	Black, Red
Country of origin	Germany
Dust extraction port	Yes
Power source	Battery
Diamond disc	-
Battery included	No
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Package depth	898 mm
Package width	5400 mm
Package height	2000 mm
Package weight	1345 g
