A
Rated voltage (DC voltage)
21.6 V
Weight in accordance with EPTA procedure
01/2003
3.9 kg
Dimensions (L x W x H) 393 mm x 208 mm x 241 mm
Base plate 298 mm x 137 mm
Specified blade diameter
160…165 mm
Saw blade disc thickness
0.5…1.5 mm
Kerf width
1.5…2.0 mm
Saw blade arbor size
20 mm
Cutting depth with scale setting
Bracket 0°: 57 mm
Bracket 45°: 42 mm
Speed under no load
4,000/min
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a
standardized test given in EN 60745 and may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure. The declared vibration emission level represents the main applications of
the tool. However if the tool is used for different applications, with different accessories or is poorly maintained,
the vibration emission may differ. This may significantly increase the exposure level over the total working
period. An estimation of the level of exposure to vibration should also take into account the times when the
tool is switched off or when it is running but not actually doing the job. This may significantly reduce the
exposure level over the total working period. Identify additional safety measures to protect the operator from
the effects of vibration such as: maintaining the tool and the accessories, keeping hands warm, organization
of work patterns.
Noise and vibration information for the SCW 22-A (measured in accordance with EN 60745-2-5):
Typical A-weighted sound power level 104 dB (A)
Typical A-weighted emission sound pressure level 93 dB (A)
Uncertainty for the given sound level
3 dB (A)
Triaxial vibration values (vibration vector sum)
Sawing in wood, a
h
1.2 m/st
Uncertainty (K) 1.5 m/st
en
22
