Hilti SCW 22-A User Manual

2.2 Switch
On / off switch with switch-on interlock
2.3 Grips
Grip and auxiliary grip
2.4 Protective device
Blade guard and pivoting guard
2.5 Lubrication
Grease lubrication
2.6 Power tool protection against overload and overheating
The power tool is equipped with an electronic protection system to prevent overloading and overheating. The
power tool switches itself off automatically in the event of overloading and overheating. After releasing the on
/ off switch, the power tool may not restart immediately when the switch is pressed again (while the power
tool is cooling down).
2.7 Lithium
ತ
ion battery charge status
When a lithium-ion battery is used, the charge status can be indicated by gently pressing one of the battery
release buttons (press until resistance is felt - do not release the battery). The display on the rear of the battery
provides the following information:
LEDs light constantly LEDs blink Charge status C
LED 1,2,3,4
-
C ฺ 75 %
LED 1,2,3
-
50 % ู C < 75 %
LED 1,2
-
25 % ู C < 50 %
LED 1
-
10 % ู C < 25 %
-
LED 1
C < 10 %
2.8 Items supplied as standard
1 Power tool
1 Saw blade
1 Hexagon socket wrench
1 Operating instructions
1 Hilti toolbox (optional)
1 Cardboard box (optional)
1 Rip fence
1 Connecting piece for sawdust extractor
1 Guide rail adapter (optional)
2.9 Additional items required for operating the tool
For SCW 22ತA, a B22/2.6 lithium-ion battery pack and C4/36 or C4/36ತACS battery charger.
NOTE
Depending on the version, these items may be supplied with the power tool.
en
21

Hilti SCW 22-A Specifications

General

Blade diameter	165 mm
Idle speed (max)	4000 RPM
Cutting depth (45º)	42 mm
Cutting depth (90º)	57 mm
Sound pressure level	93 dB
Vibration level (wood cutting)	1.2 m/s²
Product color	Black, Red
Country of origin	Germany
Dust extraction port	Yes
Power source	Battery
Diamond disc	-
Battery included	No
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Package depth	898 mm
Package width	5400 mm
Package height	2000 mm
Package weight	1345 g
