Hilti SCW 22-A User Manual

ORIGINAL OPERATING INSTRUCTIONS
SCW 22
ತ
A cordless circular saw
It is essential that the operating instruc-
tions are read before the power tool is op-
erated for the first time.
Always keep these operating instructions
together with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to
other persons.
Contents Page
1. General information 19
2. Description 20
3. Accessories 22
4. Technical data 22
5. Safety instructions 23
6. Before use 27
7. Operation 28
8. Care and maintenance 31
9. Troubleshooting 32
10. Disposal 32
11. Manufacturer’s warranty - tools 33
12. EC declaration of conformity 34
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
power tool” always refers to the SCW 22-A cordless
circular saw.
Operating controls and indicators 1
@
Battery
;
Release buttons with additional function
(charge status display activation)
=
Charge status and fault display (lithium-ion
battery)
%
On / off switch
&
Switch-on interlock
(
Auxiliary grip
)
Drive spindle lockbutton
+
Hexagon socket wrench
§
Cutting angle scale
/
Clamping lever for cutting angle adjustment
:
Clamping screw for rip fence
·
Clamping lever for cutting depth adjustment
$
45°cutting line indicator
£
0°cutting line indicator
|
Rip fence
¡
Pivoting guard
Q
Base plate
W
Guard
E
Hose connector (chip deflector)
R
Drive spindle
T
Mounting flange
Z
Clamping flange
U
Clamping screw
I
Cutting depth scale
O
Pivoting guard operating lever
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
en
19

Hilti SCW 22-A Specifications

General

Blade diameter	165 mm
Idle speed (max)	4000 RPM
Cutting depth (45º)	42 mm
Cutting depth (90º)	57 mm
Sound pressure level	93 dB
Vibration level (wood cutting)	1.2 m/s²
Product color	Black, Red
Country of origin	Germany
Dust extraction port	Yes
Power source	Battery
Diamond disc	-
Battery included	No
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Package depth	898 mm
Package width	5400 mm
Package height	2000 mm
Package weight	1345 g
