8 English
@
Dust shield
;
TE-C Click chuck
=
Forward / reverse switch
%
Lockbutton for continuous operation
&
Grip
(
Supply cord
)
Control switch
+
Side handle with depth gauge
3.2 Intended use
The product described is an electrically powered rotary hammer. It is designed for drilling in concrete,
masonry and natural stone.
Hilti products are designed for professional use and may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must be informed of any particular hazards that may be
encountered. The product described and its ancillary equipment may present hazards when used incorrectly
by untrained personnel or when used not as directed.
▶ The power tool may be operated only when connected to a power supply providing a voltage and
frequency in compliance with the information given on its type plate.
3.3 Items supplied
Rotary hammer, side handle, depth gauge, operating instructions.
Note
For safe, reliable operation, use only genuine Hilti spare parts and accessories. Spare parts,
accessories and consumables approved by Hilti for use with this product can be found at your Hilti
Center or at www.hilti.group.
4 Technical data
Note
For details of the rated voltage, current, frequency and/or input power, please refer to the power tool’s
country-specific type identification plate.
When powered by a generator or transformer, the generator or transformer’s power output must be at least
twice the rated input power shown on the rating plate of the power tool. The operating voltage of the
transformer or generator must always be within +5% and -15% of the rated voltage of the power tool.
TE 1
Weight in accordance with EPTA procedure 01
2.4 kg
Ø Hammer drill bits
4 mm …18 mm
Maximum length of the depth gauge
180 mm
4.1 Noise information and vibration values in accordance with EN 60745
The sound pressure and vibration values given in these instructions have been measured in accordance with
a standardized test and may be used to compare one power tool with another. They may be used for a
preliminary assessment of exposure.
The data given represents the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools or is poorly maintained, the data may vary. This may
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This may significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: Maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
Sound (power) level (L
WA
)
100 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A)
Printed: 31.05.2017 | Doc-Nr: PUB / 5138980 / 000 / 03
