Hilti TE 1 - Operation; Fitting the side handle; Fitting and removing accessory tool

English 9
Emission sound pressure level (L
pA
)
89 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A)
Vibration information
Hammer drilling in concrete (a
h, HD
)
15 m/s²
Uncertainty for the given vibration value (K)
1.5 m/s²
5 Operation
5.1 Fitting the side handle
CAUTION
Risk of injury! The depth gauge, if fitted but not used, might hinder the operator.
▶ Remove the depth gauge from the tool.
CAUTION
Risk of injury! Loss of control over the rotary hammer drill.
▶ Check that the side handle is fitted correctly and tightened securely. Check that the clamping
band is engaged in the groove in the tool.
▶ Fit the side handle.
5.2 Fitting / removing the accessory tool
Note
Use of unsuitable grease may cause damage to the product. Use only the recommended grease
supplied by Hilti.
Printed: 31.05.2017 | Doc-Nr: PUB / 5138980 / 000 / 03
