6 English 2102964
*2102964*
3.7 Service indicator
The product has an LED service indicator.
Status Meaning
Service indicator shows Servicing is due.
Service indicator flashes The product is faulty. Have the combihammer re-
paired by Hilti Service.
3.8 Items supplied
Combihammer, side handle, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or online at:
www.hilti.group.
4 Technical data
4.1 Combihammer
For rated voltage, rated current, frequency and/or input power, refer to the country-specific type
identification plate.
If the device is powered by a generator or transformer, the generator or transformer’s power output must be
at least twice the rated input power shown on the rating plate of the device. The operating voltage of the
transformer or generator must always be within +5 % and -15 % of the rated voltage of the device.
TE 50AVR
Weight in accordance with EPTA procedure 01
6.1 kg
Storage temperature
−20 ℃ … 70 ℃
Ambient temperature for operation
−17 ℃ … 60 ℃
Ø hammer drill bits
12 mm … 32 mm
Ø drill bits for wood
6 mm … 35 mm
Ø drill bits for metal
6 mm … 13 mm
4.2 Noise information and vibration values determined in accordance with EN 60745
The sound pressure and vibration values given in these instructions have been measured in accordance
with a standardized test and may be used to compare one electric tool with another. They may be used
for a preliminary assessment of exposure. The data given represents the main applications of the electric
tool. However, if the electric tool is used for different applications, with different accessory tools, or is poorly
maintained, the data may vary. This may significantly increase exposure over the total working period. An
accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This may significantly reduce exposure over the
total working period. Identify additional safety measures to protect the operator from the effects of noise
and/or vibration, for example: maintenance of the electric tool and the accessories, keeping the hands warm,
organization of work patterns.
Noise emission values
TE 50AVR
Sound (power) level (L
WA
)
108 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A)
Sound pressure level (L
pA
)
97 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A)
Total vibration
TE 50AVR
Drilling in metal (a
h,D
)
< 5 m/s²
Hammer drilling in concrete (a
h,HD
)
9 m/s²
Printed: 12.12.2018 | Doc-Nr: PUB / 5283577 / 000 / 02

Hilti TE 50-AVR Specifications

General

Drilling	Yes
Chuck type	SDS Max
Product color	Black, Red
Country of origin	Germany
Impact rate	3180 bpm
Rated speed (max)	360 RPM
Impact energy (max)	6 J
Vibration level (hammer drilling)	9 m/s²
Drilling diameter in concrete (max)	40 mm
Optimum drilling diameter (concrete)	16 - 32 mm
Input power	1100 W
Power source	AC
Power plug type	Type C
Noise level	108 dB
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Weight	6100 g
Package depth	3456 mm
Package width	2000 mm
Package height	4500 mm
Package weight	4500 g
