Hilti TE 70-AVR Manual

90 ﻋﺮﺑﻲ 2063040
*2063040*
3.5.1ﺣﺎﻟﺔﻣﺒﻴﻦﺍﻟﺨﺪﻣﺔ
ﺍﻟﺤﺎﻟﺔﺍﻻﺳﺘﻌﻤﺎﻝ
ﻳﻀﻲءﻣﺒﻴﻦﺍﻟﺨﺪﻣﺔﺑﺎﻟﻠﻮﻥﺍﻷﺣﻤﺮ.ﻫﺬﺍﻳﻌﻨﻲﺃﻧﻪﺣﺎﻥﻣﻮﻋﺪﺇﺟﺮﺍءﺍﻟﺨﺪﻣﺔ.
ﻳﻮﻣﺾﻣﺒﻴﻦﺍﻟﺨﺪﻣﺔﺑﺎﻟﻠﻮﻥﺍﻷﺣﻤﺮ.ﺍﻋﻤﻞﻋﻠﻰﺇﺻﻼﺡﺍﻟﻤﻄﺮﻗﺔﻣﺘﻌﺪﺩﺓﺍﻷﻏﺮﺍﺽﻟﺪﻯ
ﻣﺮﻛﺰﺧﺪﻣﺔHilti.
3.6ﻣﺠﻤﻮﻋﺔﺍﻟﺘﺠﻬﻴﺰﺍﺕﺍﻟﻤﻮﺭﺩﺓ
ﺍﻟﻤﻄﺮﻗﺔﻣﺘﻌﺪﺩﺓﺍﻷﻏﺮﺍﺽ،ﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲ،ﺩﻟﻴﻞﺍﻻﺳﺘﻌﻤﺎﻝ.
ﺗﺠﺪﺍﻟﻤﺰﻳﺪﻣﻦﻣﻨﺘﺠﺎﺕﺍﻟﻨﻈﺎﻡﺍﻟﻤﺴﻤﻮﺡﺑﻬﺎﻟﻤﻨﺘﺠﻚﻟﺪﻯﻣﺘﺠﺮHilti Storeﺃﻭﻋﻠﻰ:www.hilti.group|ﺍﻟﻮﻻﻳﺎﺕ
ﺍﻟﻤﺘﺤﺪﺓﺍﻷﻣﺮﻳﻜﻴﺔ:www.hilti.com
4ﺍﻟﻤﻮﺍﺻﻔﺎﺕﺍﻟﻔﻨﻴﺔ
ﻳﺮﺟﻰﺍﻟﺘﻌﺮﻑﻋﻠﻰﺍﻟﺠﻬﺪﺍﻻﺳﻤﻲﻭﺍﻟﺘﻴﺎﺭﺍﻻﺳﻤﻲﻭﺍﻟﺘﺮﺩﺩﻭ/ﺃﻭﺍﻻﺳﺘﻬﻼﻙﺍﻻﺳﻤﻲﻣﻦﻟﻮﺣﺔﺻﻨﻊﺍﻟﺠﻬﺎﺯ
ﺍﻟﺨﺎﺻﺔﺑﺎﻟﺒﻠﺪﺍﻟﻤﻌﻨﻲ.
ﻓﻲﺣﺎﻟﺔﺍﻟﺘﺸﻐﻴﻞﻣﻦﻣﻮﻟﺪﺃﻭﻣﺤﻮﻝ،ﻓﺈﻧﻪﻳﺠﺐﺃﻻﺗﻘﻞﻗﺪﺭﺓﺍﻟﺨﺮﺝﺍﻟﺨﺎﺻﺔﺑﻪﻋﻦﺿﻌﻒﻗﺪﺭﺓﺍﻟﺪﺧﻞ
ﺍﻻﺳﻤﻴﺔﺍﻟﻮﺍﺭﺩﺓﻋﻠﻰﻟﻮﺣﺔﺻﻨﻊﺍﻟﺠﻬﺎﺯ.ﺟﻬﺪﺗﺸﻐﻴﻞﺍﻟﻤﺤﻮﻝﺃﻭﺍﻟﻤﻮﻟﺪﻳﺠﺐﺃﻥﻳﻜﻮﻥﺩﺍﺋﻤﺎﻓﻲﻧﻄﺎﻕ+5%ﻭ
-15%ﻣﻦﺍﻟﺠﻬﺪﺍﻟﻜﻬﺮﺑﺎﺋﻲﺍﻻﺳﻤﻲﻟﻠﺠﻬﺎﺯ.
TE 70AVRTE 70-ATC/AVRTE 80-ATC/AVR
ﺍﻟﻮﺯﻥﻃﺒﻘﺎﻟﺒﺮﻭﺗﻮﻛﻮﻝ
EPTA 01
8.3ﻛﺠﻢ9.5ﻛﺠﻢ9.7ﻛﺠﻢ
ﻃﺎﻗﺔﺍﻟﻄﺮﻕﺍﻟﻔﺮﺩﻱ
ﻃﺒﻘﺎﻟﺒﺮﻭﺗﻮﻛﻮﻝEPTA
05
11.5ﺟﻮﻝ11.5ﺟﻮﻝ11.5ﺟﻮﻝ
Øﺭﻳﺸﺔﺛﻘﺐﺩﻗﺎﻗﺔ
12ﻣﻢ…55ﻣﻢ12ﻣﻢ…55ﻣﻢ12ﻣﻢ…55ﻣﻢ
Øﺭﻳﺸﺔﺛﻘﺐﺍﻷﺧﺸﺎﺏ
10ﻣﻢ…32ﻣﻢ10ﻣﻢ…32ﻣﻢ10ﻣﻢ…32ﻣﻢ
Øﺭﻳﺸﺔﺛﻘﺐﺍﻟﻤﻌﺎﺩﻥ
0ﻣﻢ…20ﻣﻢ0ﻣﻢ…20ﻣﻢ0ﻣﻢ…20ﻣﻢ
4.1ﻣﻌﻠﻮﻣﺎﺕﺍﻟﻀﺠﻴﺞﻭﻗﻴﻢﺍﻻﻫﺘﺰﺍﺯﻃﺒﻘﺎﻟﻠﻤﻮﺍﺻﻔﺔEN 60745
ﺗﻢﻗﻴﺎﺱﻗﻴﻢﺿﻐﻂﺍﻟﺼﻮﺕﻭﺍﻻﻫﺘﺰﺍﺯﺍﻟﻮﺍﺭﺩﺓﻓﻲﻫﺬﺍﺍﻟﺪﻟﻴﻞﻃﺒﻘﺎﻟﻌﻤﻠﻴﺔﻗﻴﺎﺱﻣﻌﺎﻳﺮﺓﻭﻳﻤﻜﻦﺍﻻﺳﺘﻌﺎﻧﺔﺑﻬﺎ
ﻓﻲﻣﻘﺎﺭﻧﺔﺍﻷﺩﻭﺍﺕﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻣﻊﺑﻌﻀﻬﺎﺍﻟﺒﻌﺾ.ﻭﻫﻲﺗﺼﻠﺢﺃﻳﻀﺎﻟﺘﻘﺪﻳﺮﺍﻟﻤﺨﺎﻃﺮﺑﺼﻮﺭﺓﻣﺆﻗﺘﺔ.ﺍﻟﻤﻮﺍﺻﻔﺎﺕ
ﺍﻟﻮﺍﺭﺩﺓﺗﺘﻌﻠﻖﺑﺎﻻﺳﺘﺨﺪﺍﻣﺎﺕﺍﻷﺳﺎﺳﻴﺔﻟﻸﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ.ﺃﻣﺎﺇﺫﺍﺗﻢﺍﺳﺘﺨﺪﺍﻡﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻓﻲﺗﻄﺒﻴﻘﺎﺕ
ﺃﺧﺮﻯﻣﻊﺃﺩﻭﺍﺕﺷﻐﻞﻣﺨﺎﻟﻔﺔﻟﻠﻤﻮﺍﺻﻔﺎﺕﺃﻭﺩﻭﻥﺻﻴﺎﻧﺔﻛﺎﻓﻴﺔ،ﻓﻔﻲﻫﺬﻩﺍﻟﺤﺎﻟﺔﻗﺪﺗﺨﺘﻠﻒﺍﻟﺒﻴﺎﻧﺎﺕ.ﻭﻗﺪ
ﻳﺰﻳﺪﻫﺬﺍﻣﻦﺍﻟﻤﺨﺎﻃﺮﺧﻼﻝﻣﺪﺓﺍﻟﻌﻤﻞﺑﺎﻟﻜﺎﻣﻞﺑﺼﻮﺭﺓﻭﺍﺿﺤﺔ.ﻭﻟﺘﻘﺪﻳﺮﺍﻟﻤﺨﺎﻃﺮﺗﻘﺪﻳﺮﺍﺩﻗﻴﻘﺎﻳﻨﺒﻐﻲﺃﻳﻀﺎ
ﻣﺮﺍﻋﺎﺓﺍﻷﻭﻗﺎﺕﺍﻟﺘﻲﻳﺘﻢﻓﻴﻬﺎﺇﻳﻘﺎﻑﺍﻟﺠﻬﺎﺯﺃﻭﺍﻟﺘﻲﻳﻜﻮﻥﻓﻴﻬﺎﺍﻟﺠﻬﺎﺯﻣﺸﻐﻼﻭﻟﻜﻦﺩﻭﻥﺍﺳﺘﺨﺪﺍﻡﺣﻘﻴﻘﻲ.ﻭﻗﺪ
ﻳﻘﻠﻞﻫﺬﺍﻣﻦﺍﻟﻤﺨﺎﻃﺮﺧﻼﻝﻣﺪﺓﺍﻟﻌﻤﻞﺑﺎﻟﻜﺎﻣﻞﺑﺼﻮﺭﺓﻭﺍﺿﺤﺔ.ﺍﺣﺮﺹﻋﻠﻰﻣﺮﺍﻋﺎﺓﺗﺪﺍﺑﻴﺮﺍﻟﺴﻼﻣﺔﺍﻹﺿﺎﻓﻴﺔ
ﻟﺤﻤﺎﻳﺔﺍﻟﻤﺴﺘﺨﺪﻡﻣﻦﺗﺄﺛﻴﺮﺍﻟﺼﻮﺕﻭ/ﺃﻭﺍﻻﻫﺘﺰﺍﺯﺍﺕﻣﺜﻞ:ﺻﻴﺎﻧﺔﺍﻷﺩﺍﺓﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔﻭﺃﺩﻭﺍﺕﺍﻟﻌﻤﻞﻭﺍﻟﺤﻔﺎﻅﻋﻠﻰ
ﺍﻷﻳﺪﻱﻓﻲﺣﺎﻟﺔﺩﺍﻓﺌﺔﻭﺗﻨﻈﻴﻢﻣﺮﺍﺣﻞﺍﻟﻌﻤﻞ.
ﻗﻴﻢﺍﻟﻀﺠﻴﺞﺍﻟﻤﻨﺒﻌﺚ
TE 70AVRTE 70-ATC/AVRTE 80-ATC/AVR
ﻣﺴﺘﻮﻯﺷﺪﺓﺍﻟﺼﻮﺕ)L
WA
(
113ﺩﻳﺴﻴﺒﻞ)A(113ﺩﻳﺴﻴﺒﻞ)A(113ﺩﻳﺴﻴﺒﻞ)A(
ﻧﺴﺒﺔﺍﻟﺘﻔﺎﻭﺕﻟﻤﺴﺘﻮﻯﺷﺪﺓﺍﻟﺼﻮﺕ
)K
WA
(
3ﺩﻳﺴﻴﺒﻞ)A(3ﺩﻳﺴﻴﺒﻞ)A(3ﺩﻳﺴﻴﺒﻞ)A(
ﻣﺴﺘﻮﻯﺿﻐﻂﺍﻟﺼﻮﺕﺍﻟﻤﻨﺒﻌﺚ)L
pA
(
102ﺩﻳﺴﻴﺒﻞ)A(102ﺩﻳﺴﻴﺒﻞ)A(102ﺩﻳﺴﻴﺒﻞ)A(
ﻧﺴﺒﺔﺍﻟﺘﻔﺎﻭﺕﻟﻤﺴﺘﻮﻯﺿﻐﻂﺍﻟﺼﻮﺕ
)K
pA
(
3ﺩﻳﺴﻴﺒﻞ)A(3ﺩﻳﺴﻴﺒﻞ)A(3ﺩﻳﺴﻴﺒﻞ)A(

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
