Hilti TE 70-AVR Manual

*2063040*
2063040 ﻋﺮﺑﻲ 91
ﻗﻴﻢﺍﻻﻫﺘﺰﺍﺯﺍﻹﺟﻤﺎﻟﻴﺔ
TE 70AVRTE 70-ATC/AVRTE 80-ATC/AVR
ﺍﻟﺜﻘﺐﺑﺎﻟﻄﺮﻕﻓﻲﺍﻟﺨﺮﺳﺎﻧﺔ)a
h, HD
(
10ﻡ/ﺛﺎﻧﻴﺔ²10ﻡ/ﺛﺎﻧﻴﺔ²7.5ﻡ/ﺛﺎﻧﻴﺔ²
ﺍﻟﻨﻘﺮﺑﺎﻹﺯﻣﻴﻞ)a
h, Cheq
(
9ﻡ/ﺛﺎﻧﻴﺔ²9ﻡ/ﺛﺎﻧﻴﺔ²7ﻡ/ﺛﺎﻧﻴﺔ²
ﻧﺴﺒﺔﺍﻟﺘﻔﺎﻭﺕ)K(
1.5ﻡ/ﺛﺎﻧﻴﺔ²1.5ﻡ/ﺛﺎﻧﻴﺔ²1.5ﻡ/ﺛﺎﻧﻴﺔ²
5ﺍﻻﺳﺘﻌﻤﺎﻝ
5.1ﺗﺮﻛﻴﺐﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲ2
ﺍﺣﺘﺮﺱ:
ﺧﻄﺮﺍﻹﺻﺎﺑﺔﻓﻘﺪﺍﻥﺍﻟﺴﻴﻄﺮﺓﻋﻠﻰﺍﻟﺪﻗﺎﻕﻣﺘﻌﺪﺩﺍﻷﻏﺮﺍﺽ.
◀
ﺗﺄﻛﺪﺃﻥﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲﻣﺮﻛﺐﻭﻣﺜﺒﺖﺑﺸﻜﻞﺳﻠﻴﻢ.ﺗﺄﻛﺪﻣﻦﺗﻮﺍﺟﺪﺷﺮﻳﻂﺍﻟﺸﺪﻓﻲﺍﻟﺤﺰﺍﻟﻤﺨﺼﺺﻟﻪ
ﺑﺎﻟﺠﻬﺎﺯ.
◀ﻗﻢﺑﺘﺮﻛﻴﺐﺍﻟﻤﻘﺒﺾﺍﻟﺠﺎﻧﺒﻲ.
5.2ﺗﺮﻛﻴﺐ/ﺧﻠﻊﺃﺩﺍﺓﺍﻟﺸﻐﻞ3
ﻗﺪﻳﺆﺩﻱﺍﺳﺘﺨﺪﺍﻡﺷﺤﻢﻏﻴﺮﻣﻨﺎﺳﺐﺇﻟﻰﺗﻌﺮﺽﺍﻟﺠﻬﺎﺯﻟﻠﻀﺮﺭ.ﺍﻗﺘﺼﺮﻋﻠﻰﺍﺳﺘﺨﺪﺍﻡﺍﻟﺸﺤﻢﺍﻷﺻﻠﻲﻣﻦ
Hilti.
ﻗﺒﻞﻛﻞﺍﺳﺘﺨﺪﺍﻡ،ﺍﻓﺤﺺﺍﻷﺩﺍﺓﻟﻠﺘﺄﻛﺪﻣﻦﻋﺪﻡﻭﺟﻮﺩﺃﺿﺮﺍﺭﺑﻬﺎﻭﺗﺂﻛﻞﻏﻴﺮﻣﺘﺴﺎﻭٍﻭﻗﻢﺑﺎﺳﺘﺒﺪﺍﻟﻬﺎﻋﻨﺪ
ﺍﻟﻠﺰﻭﻡ.
◀
ﻗﻢﺑﺘﺮﻛﻴﺐ/ﺧﻠﻊﺍﻷﺩﺍﺓ.
5.3ﺍﻟﺜﻘﺐﺑﺪﻭﻥﻃﺮﻕ4
ﻳﻤﻜﻦﺇﺟﺮﺍءﺍﻟﺜﻘﺐﺑﺪﻭﻥﻃﺮﻕﺑﺎﺳﺘﺨﺪﺍﻡﻋﺪﺩﻣﺰﻭﺩﺓﺑﻄﺮﻑﺇﺩﺧﺎﻝﺧﺎﺹ.ﺗﺘﺎﺡﺍﻟﻌﺪﺩﺍﻟﺘﺎﻟﻴﺔﺿﻤﻦ
ﺑﺮﻧﺎﻣﺞﺍﻟﻌﺪﺩﻣﻦHilti.
ﻳﻤﻜﻦﺑﺎﺳﺘﺨﺪﺍﻡﺍﻟﻈﺮﻑﺳﺮﻳﻊﺍﻟﺮﺑﻂﺗﺜﺒﻴﺖﺭﻳﺸﺔﺛﻘﺐﺍﻟﺨﺸﺐﺃﻭﺭﻳﺸﺔﺛﻘﺐﺍﻟﻔﻮﻻﺫﻋﻠﻰﺳﺒﻴﻞﺍﻟﻤﺜﺎﻝ
ﻓﻲﺳﺎﻕﺃﺳﻄﻮﺍﻧﻴﺔﻣﻊﺍﻟﻘﻴﺎﻡﺑﺎﻟﺜﻘﺐﺑﺪﻭﻥﻃﺮﻕ.
◀
ﺍﺿﺒﻂﻣﻔﺘﺎﺡﺍﺧﺘﻴﺎﺭﺍﻟﻮﻇﻴﻔﺔﻋﻠﻰﻭﺿﻊ"ﺍﻟﺜﻘﺐﺍﻟﻤﻄﺮﻗﻲ".
5.4ﺍﻟﺘﻘﻠﻴﺐ4
ﻻﺗﺴﺘﺨﺪﻡﺃﺩﺍﺓﺍﻟﺘﻘﻠﻴﺐﺇﻻﻣﻊﻇﺮﻑﺍﻟﺮﺑﻂﺍﻟﺴﺮﻳﻊ.
◀
ﺍﺿﺒﻂﻣﻔﺘﺎﺡﺍﺧﺘﻴﺎﺭﺍﻟﻮﻇﻴﻔﺔﻋﻠﻰﻭﺿﻊ"ﺍﻟﺜﻘﺐﺍﻟﻤﻄﺮﻗﻲ"ﺛﻢﻗﻢﺑﺘﺮﻛﻴﺐﺃﺩﺍﺓﺍﻟﺘﻘﻠﻴﺐﻓﻲﺍﻟﻈﺮﻑﺳﺮﻳﻊ
ﺍﻟﺮﺑﻂ.
5.5ﺿﺒﻂﺍﻟﻘﺪﺭﺓ
TE 70-ATC/AVR
TE 80-ATC/AVR
ﻻﻳﻤﻜﻦﺿﺒﻂﺍﻟﻘﺪﺭﺓﺇﻻﺃﺛﻨﺎءﺗﺸﻐﻴﻞﺍﻟﺠﻬﺎﺯ.
ﻟﻀﺒﻂﺍﻟﺠﻬﺎﺯﻋﻠﻰﻧﺼﻒﺍﻟﻘﺪﺭﺓ،ﺍﺿﻐﻂﻋﻠﻰﺯﺭ"ﻧﺼﻒﺍﻟﻘﺪﺭﺓ".ﻳﺘﻢﺍﻹﺷﺎﺭﺓﺇﻟﻰﺗﻘﻠﻴﻞﺍﻟﻘﺪﺭﺓﻣﻦﺧﻼﻝ
ﺇﺿﺎءﺓﻣﺒﻴﻦﺍﻟﻘﺪﺭﺓ.ﻣﻦﺧﻼﻝﺍﻟﻀﻐﻂﻣﺠﺪﺩﺍﻋﻠﻰﺯﺭ»ﻧﺼﻒﺍﻟﻘﺪﺭﺓ«ﻳﺘﻢﺿﺒﻂﺍﻟﺠﻬﺎﺯﻣﺮﺓﺃﺧﺮﻯﻋﻠﻰ
ﺍﻟﻘﺪﺭﺓﺍﻟﻜﺎﻣﻠﺔ،ﻭﻳﻨﻄﻔﺊﻣﺒﻴﻦﺍﻟﻘﺪﺭﺓ.
ﻓﺈﺫﺍﺗﻢﺇﻳﻘﺎﻑﺍﻟﻤﻄﺮﻗﺔﻣﺘﻌﺪﺩﺓﺍﻷﻏﺮﺍﺽﻭﺗﺸﻐﻴﻠﻬﺎﻣﻦﺟﺪﻳﺪ،ﻓﺴﻮﻑﻳﺘﺎﺡﺍﻟﺘﺸﻐﻴﻞﻣﺮﺓﺃﺧﺮﻯﺑﺎﻟﻘﺪﺭﺓ
ﺍﻟﻜﺎﻣﻠﺔ.

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
